JET-POWER FILTER III 2700 HIBRID

WITH UPS

(UNINTERRUPTIBLE POWER SUPLY)

INSTRUCTION MANUAL

This system combines the best of both worlds: the economy and support of the electrical grid with the security and autonomy of a battery bank.

An excellent option for successful programming of any 28VDC aircraft, as it is a power supply developed with a high standard of protection for the aircraft, ensuring uninterrupted power supply during hangar power outages. The UPS batteries also assist with starting, drawing less power from the mains. This is ideal for installations with poor capacity and low operating conditions. It is also supplied with 4x10mm² input cables and 2x95mm² output cables from the brand "JET-POWER CABLE", both in ORANGE.

The UPS (Uninterruptible Power Supply) maintains the output voltage to the aircraft for several minutes, giving time for the hangar's emergency generator to kick in or for saving the programming.

 The Jet-Power Filter III 2700 electric GPU is the only Brasilian model equipped with an internal UPS. When the mains power goes out, the GPU continues supplying voltage to the aircraft, preventing loss of programming. This allows for unhurried completion and saving.

The Jet-Power Filter III 2700 electric GPU is compatible with all 28VDC aircraft with a maximum peak current of up to 2700A, with a three-phase 220/380VAC input, externally adjustable, and with a high-performance DC current filter. It is a highly reliable electronic model with an automatic current limiter, requiring no operator adjustment, and features external output voltage adjustment on the panel with seven positions. It offers active electronic protection against phase failure, overcurrent, and overvoltage, with a voltmeter and ammeter. It is the top-of-the-line national model. Manufactured on an industrial scale, without handcrafted parts, and using high-quality components. It is housed in a new metal case with full opening, providing easy access to all components. The hinged lid is manufactured in a single piece. The Jet-Power Filter III 2700 electric GPU thanks to the assistance provided by the batteries during startup, it operates with up to a 25% voltage drop in the electrical grid. Start-ups are also good on weak grids.

Without a doubt, the best electric GPU manufactured in Brazil. The best cost/benefit ratio, because despite the higher initial investment, its long lifespan, without defects, will fully compensate.

Warranty: 3 (three) years, except for the batteries, which have a 1-year warranty.

Manufactured in series, with a delivery time of 3 to 20 days, according to the schedule at the time of purchase.

When ordering, please specify the desired plug type to be installed on the input cable: 220V three-phase, 63A N-4579 blue or 380V three-phase, 63A N-4576 red.

These can be checked, calibrated, or repaired by the customer themselves, following the detailed instructions in the manual, or via video call, without voiding the warranty.

General Characteristics:

Models for intensive and professional use, where quality comes before cost;

Automatic starting current limitation with reduced power consumption, without the need for adjustments or operator knowledge;

Easy-to-use operational controls, capable of operating outdoors without risk of electric shock.

3D design and electrical and electronic circuits resistant to vibrations, water, and sea air, unmatched by national equipment.

Horizontal model, easy to move on runways or maintenance hangars due to its reduced weight and size;

Technical and Operational Characteristics:

Input: 220/380VAC three-phase, 50/60Hz, with external adjustment;

Output: 28VDC, with adjustment switch on the panel, adjusting from 25 to 32VDC, all with seven adjustment positions;

Maximum output currents: 2,700 Amperes peak for 15 seconds; 1,600 Amperes peak for 45 seconds. 450 A continuous;

Maximum power: 20 kVA peak, at full load. Note: The power required in the installation may be much lower if the maximum current is not used. Example: With a load of up to 1200A at the output, a power of 10 KVA will be required;

Dimensions: Length 1150 mm, width 710 mm, height 940 mm;

Weight: 310Kg.

Ripple: 0.003% at 100A; 0.008% at 300A;

Starting aid, reducing power consumption with less voltage drop during startup.

New active electronic circuit for protecting the aircraft being serviced, protecting it in case of failures;

Equipped with a UPS, using 02 MOURA AGM/VRLA special batteries;

Single six-phase rectification circuit at 60°, with high-efficiency filtering;

Forced cooling of the 6 powerful 28VDC rectifiers, with fan;

Electronic circuit indicating the presence of the 3 power phases;

Side hooks to house the input and output cables;

Input cable, 4x10mm² (4x7AWG) gauge, "JET-POWER CABLE" brand, orange color, 20 meters long (65 ft), with a three-phase plug according to your installation (When purchasing, please inform us of the available three-phase voltage, the desired plug model, if you need a longer input cable, or if you want any optional extras);

Parallel output cable, 2 x 120mm² (2x250MCM) gauge, orange color, flexible, "JET-POWER CABLE" brand, 5 meters (16 ft) long, with a standard 28VDC plug;

Short-circuit protection using a fast-acting circuit breaker with internal access;

Service outlets are always available for 127V and 220V, with any three-phase power supply voltage.

NEW MODEL, mounted on a lightweight chassis, yet with excellent mechanical resistance, featuring 4 casters with large, durable 8-inch wheels, with a chemically treated metal casing to protect against corrosion and electrostatic polyester paint in white; Full access for maintenance. Easy panel opening with only 2 screws on the sides. One-piece forward-hinged cover. Possibility of optional outlets to service other aircraft under maintenance.

Runway warning flasher on the upper part of the cowling, with electronic circuit;

Control panel illuminated by LED strip and sealed to be resistant to sun and rain, placed in an easily accessible location, containing the following parts:

1 Voltmeter with a scale of 0 to 40VDC;

1 Ammeter with a scale of 0 to 2500A;

1 Pushbutton to turn the equipment on;

1 Pushbutton to turn the equipment off and reset the equipment;

01 Output voltage selector switch with seven positions;

01 Overvoltage indicator light;

03 Indicator lights for phase presence at the equipment input;

01 Indicator light for GPU power-on.

 The 20000VA UPS GPU can start loads up to 1100A when disconnected from the mains. When connected, maximum consumption is 20kVA.
